Edge Holding PCB Support 9.5 (H) Natural Nylon 6/6 (PA 6/6) UL 94 V-2
Screw mount corner edge holding PCB support requires no slots or holes on PCB for maximum packaging density. Can be mounted to the corner or edge of PCB depending on supports orientation. Mounts to chassis with a metal #6 or M3.5 self-tapping screw.
Essentra part number
10035757
Material Flammability Standard
UL94 V-2
Hole A Fix Type
Snap Lock
Body Diameter
8.3mm
Hole Diameter
4.8mm
Spacer Length
9.5mm
UL/CSA Description
UL E70062
Hole Diameter B
3.1mm
Colour
Natural
Minimum Operating Temperature
-40°C
Thread Size
#6
Material
Nylon 6/6
Internal Thread Length
7.9mm
Hole B Fix Type
Female Thread Fix
